Dana 60HD Eaton Detroit TrueTrac - Front 35 Spline (4.56 & Up)

Sku: D60-DET-TT-4-35-F

Part Number: D60-DET-TT-4-35-F
Brand: Eaton Detroit

The Eaton Detroit Truetrac for Dana 60 uses a patented design of parallel axis, planetary helical gears, to provide a smooth and quiet, automatic division of torque. The Truetrac performs like an open differential under normal conditions, and automatically transfers torque to the wheel with the highest traction when required. On wet, muddy, icy or loose terrain, imbalanced gear forces automatically transfer power to the wheel with the highest traction.

Detroit TrueTrac lockers are Torsen style limited slip differentials that use helical gears instead of clutch packs to offer automatic torque biased traction to both drive wheels at all times. The ingenious design limits the speed of each wheel to 1.5 times faster or slower than the opposite wheel to provide full-time traction while still allowing for wheel speed differentiation in turns. The heavy duty all-gear design not only makes for quite and smooth operation, it requires no maintenance and will never weaken or wear out like a typical limited slip differential. These unique features make the Detroit TrueTrac ideal for race cars, rally cars, trail rigs, full size trucks, and daily drivers.

Eaton specifically designed and built the Detroit TrueTrac locker for use in 4x4 vehicles and to withstand the abuses of off-roading. Precision forged gears, high strength materials, and high-tech manufacturing procedures make the TrueTrac one of the most durable and reliable limited slip lockers on the market today. They are easy to install and maintenance free.

Features:
- Helical worm gear design, no clutches to wear out
- Can transfer up to 3.5 times more torque to high traction wheel
- Smooth and quiet operation
- Limits wheel spin-out and improves handling
- ABS Compatible

Model: 915A387

Application Axle Shafts Gear Ratio Tech Notes
Dana 60
- FRONT Axle
35 Spline 4.56 & Up - Fits Front Axle Only
- Requires Thin Cut Gear

Optional Next Generation Rear 40 Spline Assembly.18 months of design, engineering and testing, resulted in the industries strongest 40 spline rear assembly. The design completed rigorous FEA testing and analysis.
- Forged chromolyspindles, hubs, and axle shafts
- Forged spindles have 4x more yield strengththan 35 spline spindles
- Hubs with over 80,000 psi yield strength to match the spindles
- Tone rings integrated into the hub
- Forged 4340 chromoly 40 spline axle shafts that are 55% strongerthan 4340 35 spline axle shafts


Fusion Elite Kingpin 60 Front Axle Standard Features:

  • 72" width for ideal steering geometry and tire clearance when running 40" tires. Other width available or call for custom width.
  • High clearance center section with custom low profile fabricated differential cover
  • Genuine Made in the USA Spicer® 10.1" (256 mm) ring and pinion gear
  • 3.5" diameter x 7/16" wall axle tubes
  • Lifetime Warranty US Made Chromoly axle shafts with 1480 solid u-joints
  • Massive, race inspired Kingpin inner knuckle Cs and outer knuckles, no ball joints to wear out
  • Fully machined springless steering arm attached with 6 ARP Studs
  • Steering arm upgrades available for full hydro or virtually any application
  • 1/4" plate axle bracketry designed to be the strongest in its class
  • 8 x 6.5 bolt pattern
  • Massive 13.25" brake rotors and dual piston calipers
  • Yukon Hardcore locking hubs
